AHP Merkle overview Hydraulic cylinders
/
AHP Merkle Hydraulic Cylinder Core pull unit KZE 250 and KZEP 250

Core Pull Unit

Block cylinder with system port

Things to know about the KZE 250 and KZEP 25

Specially designed for core pulling
Maximum operating pressure 250bar
Piston diameters 32mm, 40mm and 50mm
Ground, hardened and hard chrome plated piston rods
During core pulling, the full piston area is available, meaning that a smaller piston diameter is required.
Guided through high-precision cross-roller guides
End position attenuation on both sides as standard

The Core Pull Unit: The compact power pack

The Core Pull Unit from AHP Merkle is a compact solution for implementing a core pull via a hydraulic cylinder. It is compact because the Core Pull Unit is far smaller than conventional solutions. Its reverse design enables to apply pressure on the entire piston area. Conventional solutions only permit to apply pressure on the ring area. The Core Pull Unit therefore generates 1.6 times more power with the same piston dimensions. Choosing this Core Pull Unit will allow you to work with smaller piston diameters in many cases. The Core Pull Unit comes as a complete unit – the required guides are integrated in the unit. The result is a reduction of the construction length by at least 35% combined with improved handling: the Core Pull Unit is ready for direct installation.

The quality of our cylinders

AHP Merkle focuses on innovation by identifying core priorities and optimizing solutions for customers. We emphasize efficiency and cost-effectiveness while pioneering new approaches. Our systematically structured product range ensures logical consistency and high service standards. A key feature is our modular design system, allowing flexible cylinder configurations and facilitating the creation of customized products.

Declarations of conformity

Certificates

INJECTION MOuLDING COMPONENTS

CYTEC-UK – Precision Cylinder & Mould Technology

CYTECUK specializes in high-precision hydraulic cylinders, clamping systems, milling heads, and motor spindles for various industrial applications, including tool & mold making, the automotive industry, and aerospace.

Hydraulic Cylinder
Hydraulic cylinders are essential components in fluid technology, enabling precise linear movements and high forces
Core pull & locking cylinders
Core pull and locking cylinders are specialized hydraulic cylinders used in injection moulding machines for the precise movement and securing of moulds
Precision components for efficient injection molding processes
Our products, such as air valves, sliders, and gas injectors, enhance the performance and reliability of your injection moulds
Clamping systems for machine tools
CYTEC specializes in hydraulic cylinder technology, offering advanced cylinder and clamping systems, as well as essential machine components for mold construction and machining.

CyTec UK – Precision Cylinder & Mould Technology
The company is based in Oldham, UK, and provides solutions from CyTec, AHP Merkle, I-Mold, Servomold, Ermanno Balzi, and Feller Engineering.
Servo-driven mould solutions
ServoMold specializes in servo-electric automation solutions for injection moulds. They provide components like unscrewing devices and linear drives to enhance precision and efficiency in mould construction.

Email: info@cytecuk.com

The company is based in Oldham, UK, and provides solutions from CyTec, AHP Merkle, I-Mold, Servomold, Ermanno Balzi, and Feller Engineering.
